Titanium Gr 2 Pipe Fittings, ASTM B363 Titanium Gr 5 Buttweld Pipe Fittings Manufacturers and Suppliers in India
CP Titanium Grade 2 Pipe Fittings, ASME SB363 Titanium UNS R55400 Pipe Elbow Exporter, Ti GR.2 / GR. 5 Long / Short Radius Elbow Manufacturers
Ample Alloys is counted as one of the privileged manufacturers, trader, exporters and supplier of an admirable range of Titanium Gr 2 Butt Weld Pipe Fittings and Titanium Gr 5 Butt Weld Pipe Fittings. We offer the same in different types such as Titanium Gr 2 Elbow, Titanium Gr 5 Tees, Titanium Gr 2 Reducer, Titanium Gr 5 Cross, Titanium Gr 2 Stub Bends, Titanium Gr 5 End Caps, and more. With excellent formability and corrosion resistance, and moderate strength, these Titanium Gr 2 Pipe
Fittings signifies the most extensively used form of titanium. These Titanium Gr 5 Pipe Fittings is widely used in Medical, Aerospace, Chemical andMarine Processing. Our offered Titanium Gr 2 Butt Weld Fittings and Titanium Gr 5 Butt Weld Fittings being developed and designed in accordance by means of the international quality of standards at our infrastructure facility for to attain the highest scales of quality.
DIN 3.7035 Titanium Seamless Pipe Fittings, ANSI/ASME B16.9 Titanium Alloy Grade 5 Welded Pipe Fittings, Titanium UNS R50400 / UNS R55400 Buttweld Fittings, Ti Grade 2 Pipe Fittings Manufacturers
- Equivalent Grades of Titanium Pipe Fittings
- Standard Specifications of Titanium Pipe Fittings
- 大小of Titanium Buttweld Fittings
- Chemical Composition of Titanium Pipe Fittings
- Mechanical Properties of Titanium Pipe Fittings
- Types of Titanium Buttweld Fittings
- Country List where we Export & Supply
- City List where we Export & Supply
Table Of Content:
Experts in Manufacturing of:
Titanium Gr 2 / Gr 5 Butt weld Pipe Fittings Equivalent Grades :
| STANDARD | UNS | werkstoff nr。 |
| Titanium Gr 2 | R50400 | 3.7035 |
| Titanium Gr 5 | R55400 | 3.7165 |
Ti Grade 2/5 Pipe Fittings Specifications :
| Specifications : ASTM B363 / ASME SB363 |
| Dimensions : ANSI/ASME B16.9, B16.28, MSS-SP-43. |
| 大小: ½”NB to 24”NB in Sch 10s, 40s, 80s, 160s, XXS. |
| Schedule : SCH 10, SCH20, SCH30, SCH40 |
| Grade : Titanium Gr-2, Titanium Gr-5 |
| Type : Seamless / Welded / Fabricated |
Titanium Gr 2 / Gr 5 Buttweld Fittings
Seamless / Welded 100% Radiography Tested
| Products | 大小 | |
| ASTM B363 Titanium Gr 2 Elbows – Long Radius | ASTM B363 Titanium Gr 5 Stub Ends | 大小s 1/2″ – 24″ |
| ASTM B363 Titanium Gr 2 Reducing Elbows | ASTM B363 Titanium Gr 5 Reducing Crosses | |
| ASTM B363 Titanium Gr 2 45° Elbows | ASTM B363 Titanium Gr 5 180° LR Return Bends | |
| ASTM B363 Titanium Gr 2 Elbows – Short Radius | ASTM B363 Titanium Gr 5 Crosses | |
| ASTM B363 Titanium Gr 2 Tees | ASTM B363 Titanium Gr 5 Pipe Bends / Piggable Bends | |
| ASTM B363 Titanium Gr 2 Reducers | ASTM B363 Titanium Gr 5 Couplings | |
| ASTM B363钛GR 2同心还原器 | ASTM B363 Titanium Gr 5 Pipe Nipples | |
| ASTM B363 Titanium Gr 2 Tees | ASTM B363 Titanium Gr 5 180° SR Return Bends | |
| ASTM B363 Titanium Gr 2 3D Elbow | ASTM B363 Titanium Gr 5 End Caps | |
| ASTM B363 Titanium Gr 2 5D Elbow | ASTM B363 Titanium Gr 5 45° LR / SR Elbow | |
| ASTM B363钛Gr 2偏心异径接头 | ASTM B363 Titanium Gr 5 90° LR / SR Elbow | |
Chemical Composition of Titanium Gr 2 / Gr 5 Pipe Fittings :
| Grade | C | Ti | N | Fe | H | O | V | Al |
| Titanium Gr 2 | 0.1 max | 99.2 min | 0.03 max | 0.3 max | 0.015 max | 0.25 max | – | – |
| Titanium Gr 5 | 0.10 max | 90 min | 0.05 max | 0.40 max | 0.015 max | 0.20 max | 3.5-4.5 | 5.5 - -6.75马克斯 |
Mechanical Properties of Titanium Gr 2 / Gr 5 Pipe Fittings :
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Titanium Gr 2 | 4.5 g/cm3 | 1665°C（3030°F） | Psi – 39900 , MPa – 275 | Psi – 49900 , MPa – 344 | 20 % |
| Titanium Gr 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 128000 , MPa – 880 | Psi – 138000 , MPa – 950 | 14 % |
Other Types Of Titanium Gr 2 / Gr 5 Pipe Fittings
