Buttweld 45度肘部制造商在印度
在我们位于印度孟买的工厂制造的45度肘部配件
We are Global Manufacturers, Stockist, and Exporters of High Quality 45° Pipe Elbow, Stainless Steel 45 Deg Elbow, Buttweld Elbow 45 Degree, ANSI B16.9 45 Deg Pipe Fittings Elbow, ASME B16.9 45 degree Elbow, Schedule 10 45 Degree Elbow, Alloy Steel 45 Degree Buttweld Pipe Elbow, Nickel Alloy 200 45 Degree Elbow, Monel 45 Deg. Buttweld Elbow, ASTM A403 SS 45 Deg Elbows, Buttweld 45 Deg. Elbow, ANSI B16.9 45 Degree Pipe Fittings Elbow available in all dimensions.
- Buttweld 45度管肘规格
- Buttweld 45 Degree Pipe Elbow Materials & Grades
- What is a Buttweld 45 Degree Pipe Elbow?
- Buttweld 45 Degree Pipe Elbow Price in India
- 为什么选择充足的合金?
- Buttweld 45度管肘尺寸
- Buttweld 45 Degree Pipe Elbow Dimensional Tolerance
- 可用类型的Buttweld 45度管肘
- 城市我们出口和供应Buttweld 45度管肘
- Countries We Export & Supply Buttweld 45 Degree Pipe Elbow
- Buttweld 45 Degree Pipe Elbow Application Industries
印度孟买的Inconel Buttweld供应商45度肘部，1英寸臀部管道肘部，钢管肘，双工钢45度肘，Hastelloy C22 45度。管道肘，铜镍45度肘，合金20 45°肘，钢45度管肘，最多合理的价格在印度
Buttweld 45 Degree Elbow Specifications
| Dimensions | ASME / ANSI B16.9, ASME B16.28 MSS-SP-43 |
| 大小 | 无缝肘（1/2英寸24英寸），ERW /焊接 /制造肘（1/2英寸48英寸） |
| 类型 | Seamless / ERW / Welded / Fabricated |
| Thickness | Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc. |
| Form | Elbow, 45 Deg Elbow, Long Radius Elbow, Short Radius Elbow, LR Elbow, SR Elbow. |
Buttweld 45 Degree Elbow – Materials & Grades
| Stainless Steel Buttweld 45° Pipe Elbow | ASTM A403 WP316/316L, ASTM A403 SA / A 774 WP-S, WP-W, WP-WX 304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404 |
| Duplex & Super Duplex Steel Buttweld 45° Pipe Elbow | ASTM A 815, ASME SA 815 UNS NO S31803, S32205. UNS S32750, S32950. Werkstoff No. 1.4462 |
| Carbon Steel Buttweld 45° Pipe Elbow | ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70. |
| Low Temperature Carbon Steel 45° Pipe Elbow | ASTM A420 WPL3, A420 WPL6 |
| Alloy Steel Buttweld 45° Pipe Elbow | ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91 |
| Nickel Alloy Buttweld 45° Pipe Elbow | ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe. |
What is a Buttweld 45 Degree Elbow?
的功能对接焊缝45度弯头是similar as a 90° elbow, but the measurement of dimensions is different to that of the 90° elbow.
45°肘的半径与90°LR（1.5d）的半径相同。但是，面部尺寸的中心不等于半径，而在90°LR肘部中。这是从垂直于彼此的中心线的每个面到相交点的测量，图像上的距离为b。这是由于弯曲程度较小。短半径45°肘部不可用。
Buttweld 45度肘价格清单
Below is Buttweld 45 Degree Elbow price in India. This price range also depending on your order, material, dimensions and might be vary without any kind of prior notifications to our customers. For complete detailscontact现在我们并立即报价。
| 母亲ials | Price Range | Unit |
|---|---|---|
| 45 Degree Elbow | $1.00-$5.00 | USD/Piece |
| stainless steel 45 degree elbow | $ 1.00- $ 31.00 | USD/Piece |
| 钢肘，45度管配件肘，臀部焊接 | $2.50-$12.00 | 美元/千克 |
| asme b16.28 SS pipe elbow 45 degree | $ 1.00- $ 10.00 | USD/Piece |
| 45 degree (LR r=1.5d) Elbow | $0.50-$99.00 | USD/Piece |
| Sanitary grade 45 Degree Elbow | $ 1.00- $ 10.00 | USD/Piece |
| 45 degree pipe Welding elbow for Joining | $1.00-$100.00 | USD/Piece |
| 45 Degree Carbon Steel Elbow | $2.40-$2.50 | USD/Piece |
| 45 degree high pressure elbow | $40.00-$50.00 | USD/Piece |
| 45 degree Elbow ANSI B16.9 | $1.00-$25.00 | USD/Piece |
| ASME B16.9 DN 500 SCH STD CS 45 Deg. elbow | $ 5.00- $ 999.00 | USD/Piece |
| 45 degree seamless carbon steel elbow | $ 4.00- $ 10.00 | USD/Piece |
| SS 45 degree Long Butt radius welding Elbow | $ 6.69- $ 16.38 | USD/Piece |
| Galvanized Steel 45 Degree Elbow | $ 0.50- $ 100.00 | USD/Piece |
| Buttweld 45 degree Elbow | $ 1.00- $ 1000.00 | USD/Piece |
| dn80 3″ sch80 45 degree smls elbow | $0.50-$1.00 | 美元/千克 |
| Butt weld pipe fitting Elbow 45 degree | $1.00-$38.00 | USD/Piece |
| copper pipe fitting 45 degree elbow | $0.50-$3.00 | USD/Piece |
为什么选择充足的合金
- Ample Alloysis anISO 9001:2015/ ISO 14001：2015 / OHSAS 18000：2007 / PED认证的制造商和库存师Buttweld 45 degree elbows。
- We offers you an exquisite customer experience through our considerable product portfolio and a conscious and active customer-friendly team. We engineer products that are feasible and advantageous in a long run.
- 我们算作是特权的出口商和令人钦佩范围的供应商之一45 Degree Pipe Elbow。我们提供不同形式的相同形式，例如不锈钢，碳钢，合金钢，双链钢，超级双链钢，镍合金200，Monel，铜镍，Hastelloy，Alloy 20等。
- Produce qualitative range of Our offeredASME B16.9 SS 45 deg elbowis being developed and designed in accordance by means of the international quality of standards at our infrastructure facility for to attain the highest scales of quality.
- We are manufacturingButtweld 45°管道肘inseamlessor焊接form, it proudly caters the needs of our customers in Oil & Gas, Power Generation, Petrochemical, and Industrial Construction, inclusive of Upstream, Midstream, and Downstream sectors.
- 我们的ANSI B16.9 Buttweld 45° Elbowsare convenient to convey, are easy to handle, reliable, viable and come with a excellent surface finish and made with very high qaulity of row materials. TheseStainless Steel 45° Elbows根据客户规格，我们以各种尺寸和形状提供，我们以最高价格的价格制造并出售。
TO GET THE BEST DEAL E-MAIL US ON:info@amplealloys.com
Dimensions of Buttweld 45 Degree Elbow, 90° LR & 3D – as per ASME B16.9
| NPS | O.D. D |
90° Long Rad Center to End A |
45° Long Rad Center to End B |
90° 3D Center to End A |
45° 3D Center to End B |
| 1/2 | 21.3 | 38 | 16 | … | … |
| 3/4 | 26.7 | 38 | 19 | 57 | 24 |
| 1 | 33.4 | 38 | 22 | 76 | 31 |
| 1¼ | 42.2 | 48 | 25 | 95 | 39 |
| 1½ | 48.3 | 57 | 29 | 114 | 47 |
| 2 | 60.3 | 76 | 35 | 152 | 63 |
| 2½ | 73 | 95 | 44 | 190 | 79 |
| 3 | 88.9 | 114 | 51 | 229 | 95 |
| 3½ | 101.6 | 133 | 57 | 267 | 111 |
| 4 | 114.3 | 152 | 64 | 305 | 127 |
| 5 | 141.3 | 190 | 79 | 381 | 157 |
| 6 | 168.3 | 229 | 95 | 457 | 189 |
| 8 | 219.1 | 305 | 127 | 610 | 252 |
| 10 | 273 | 381 | 159 | 762 | 316 |
| 12 | 323.8 | 457 | 190 | 914 | 378 |
| 14 | 355.6 | 533 | 222 | 1067 | 441 |
| 16 | 406.4 | 610 | 254 | 1219 | 505 |
| 18 | 457 | 686 | 286 | 1372 | 568 |
| 20 | 508 | 762 | 318 | 1524年 | 632 |
| 22 | 559 | 838 | 343 | 1676年 | 694 |
| 24 | 610 | 914 | 381 | 1829 | 757 |
| 26 | 660 | 991 | 406 | 1981 | 821 |
| 28 | 711 | 1067 | 438 | 2134 | 883 |
| 30 | 762 | 1143 | 470 | 2286 | 964 |
| 32 | 813 | 1219 | 502 | 2438 | 1010 |
| 34 | 864 | 1295 | 533 | 2591 | 1073 |
| 36 | 914 | 1372 | 565 | 2743 | 1135 |
| 38 | 965 | 1448 | 600 | 2896 | 1200 |
| 40 | 1016 | 1524年 | 632 | 3048 | 1264 |
| 42 | 1067 | 1600 | 660 | 3200 | 1326 |
| 44 | 1118 | 1676年 | 695 | 3353 | 1389 |
| 46 | 1168 | 1753年 | 727 | 3505 | 1453 |
| 48 | 1219 | 1829 | 759 | 3658 | 1516年 |
Note:除非另有说明，否则尺寸为毫米。壁厚（t）必须由客户指定。
Dimensional Tolerances of Buttweld 45 Degree Elbow, 90° LR & 3D – as per ASME B16.9
| Nominal Pipe Size | 1/2 to 2½ | 3至3½ | 4 | 5 to 8 |
| 外径 at Bevel (D) |
+ 1.6 – 0.8 |
1.6 | 1.6 | + 2.4 – 1.6 |
| Inside Diameter at End | 0.8 | 1.6 | 1.6 | 1.6 |
| Center to End LR (A/B) | 2 | 2 | 2 | 2 |
| Center to End 3D (A/B) | 3 | 3 | 3 | 3 |
| Nominal Pipe Size | 10 to 18 | 20至24 | 26 to 30 | 32 to 48 |
| 外径 at Bevel (D) |
+ 4 - 3.2 |
+ 6.4 - 4.8 |
+ 6.4 - 4.8 |
+ 6.4 - 4.8 |
| Inside Diameter at End | 3.2 | 4.8 | + 6.4 - 4.8 |
+ 6.4 - 4.8 |
| Center to End LR (A/B) | 2 | 2 | 3 | 5 |
| Center to End 3D (A/B) | 3 | 3 | 6 | 6 |
| Wall Thickness (t) | Not less than 87.5% of Nominal Wall Thickness | |||
Note: Dimensional tolerances are in millimeters
Available types of Buttweld 45 Degree Elbow
| Buttweld Elbow 45 Degree | 45° Short Radius Elbow |
| Super Duplex Steel 45 Deg Elbow | Copper Nickel 45 Deg Elbow |
| Schedule 10 45 Degree Elbow | Steel Pipe Elbow |
| Stainless Steel 45 Degree Pipe Elbow | 无缝45°管道肘 |
| ANSI B16.9 45 Degree Buttweld Elbow | ASME B16.28 BUTTWELD 45度肘 |
| Hastelloy 45°管道肘 | 双链钢45°管道肘 |
| 焊接45度肘 | Inconel Butt weld 45 Deg Pipe Elbow |
| ASME B16.9 45度长半径肘 | Butt Weld Long Radius 45 Degree Elbows |
| Carbon Steel 45deg.Elbow | 高质量45°肘 |
| High Nickel Alloy 45° Elbow | ASTM A403 Stainless Steel 45 Deg Elbows |
| SS 45 Deg. Elbows | Titanium 45 Degree Elbow |
Buttweld 45度肘出口和供应城市清单
|
|
|
|
Buttweld 45 Degree Elbow Export & Supply Country List
|
|
|
|
Buttweld 45 Deg. Elbow Application Industries
ASME/ANSI B16.9 45 Degree Elbow are known to deliver exceptional performance and are generally developed for meeting the demands. We supply a wide range of Buttweld 45 Degree Pipe Elbow through a worldwide network of stock-keeping branches. These 45Deg. Buttweld Elbow is uses in various industries According to needs. Most Common Indusctris are:
- Buttweld 45° Short Radius Elbow uses in Structural Pipe
- Stainless Steel 45° Buttweld Elbow uses in Oil and Gas Pipeline
- 45° Buttweld Pipe Elbow uses in Chemical Industry
- Buttweld 45° Long Radius Elbow uses in Fabrication Industry
- 45° Buttweld Elbow uses in Food Processing Industry
- Buttweld 45 Degree Pipe Elbow uses in Heating
- 合金钢45°肘用于管道
- 45 Degree Buttweld Elbow uses in Water Supply Systems
- 45° Elbow uses in Paper & Pulp Industry
- ANSI B16.9 Buttweld 45° Pipe Elbow uses in Power Plant
- 45° Degree Elbow uses in General Purpose Applications
